Equipment Overview
The drum flour coater is designed for continuous pre-dusting of piece-shaped, strip-shaped, bone-in and irregular materials. Slow rotation in the horizontal drums brings all product surfaces into contact with flour. The machine includes flour screening and closed-loop recovery.
Key Features
- Drum tumbling: supports multi-sided flour adhesion on irregular materials.
- Flour recovery: an auger and disc flour sifter return recovered flour.
- Dual-drum design: configured with two drums.
- Continuous integration: can connect to cutting, battering, breading and freezing equipment.
Reference Models and Configuration
Final model selection and configuration are confirmed for the project process.
ModelReference ParametersFunction / Dimensions
Drum Flour CoaterPower: 4 kW; two drums; infeed and discharge belt width: 800 mmDimensions: 4,800 x 1,700 x 1,800 mm; auger and disc flour sifter recovery; SUS304
Food Applications
Piece-shaped and Strip-shaped MaterialsFor continuous pre-dusting.
Bone-in MaterialsFor flour adhesion on irregularly shaped portions.
Prepared FoodsFor pre-treatment before subsequent coating and frying.
Process Position
The final process connection is confirmed for the material condition, finished-product requirement and project arrangement.
- 01Cutting or Forming
- 02Drum Pre-dustingCurrent Equipment
- 03Battering and Breading
